MSE PRO Niobium Aluminum Carbide (Nb2AlC) MAX Phase Micron-Powder

  • $ 4900

MSE PRO™ Niobium Aluminum Carbide (Nb2AlC) MAX Phase Micron-Powder

  • Chemical Name: Niobium Aluminum Carbide (Nb2AlC)
  • CAS Number: 60687-94-7
  • Product Number: 10g (PO6725); 50g (PO6726); 100g (PO6727)
  • Appearance: Black Powder
  • Particle Size: 0.5-30μm
  • Purity: >90 wt.%


Niobium Aluminum Carbide (Nb2AlC) belongs to the family of Mn+1AXn (MAX) phases with more than 80 members. These are layered, machinable, nanolaminated ternary carbides, nitrides and borides, where M is an early transition metal, A is an A-group element, mainly from groups 13–16 and X is C or N or B. These compounds possess hexagonal crystal structure with space group P63/mmc (space group number: 194), where M atoms are in a near closed packed arrangement and are intercalated with A-group atomic layers, with the X-atoms residing in the octahedral sites between the M layers. These atomic arrangements give the MAX phases an effective laminated layered structure that leads to the naming of the MAX phase as nanolaminates. MAX phases possess a unique combination of properties, both metallic and ceramic in nature due to the layered structure. Metallic properties can include good thermal and electrical conductivities, good thermal shock resistance, excellent damage tolerance, and good machinability. Ceramic properties include low density, elastic rigidity, oxidation and creep resistance, and the ability to maintain strength up to very high temperatures.

Nb2AlC has attracted considerable interest. It not only possesses decent mechanical and thermal properties but also shows a superconducting transition at 400 mK for the thin film form. All of these properties render Nb2AlC a promising material for high-temperature structural and functional applications.

Notes: More detailed product information including SDS, certificate of analysis (COA), lead time and volume pricing are available upon request. Please contact MSE Supplies if you need bulk pricing.

MSE Supplies also offers Nb2AlC dispersions. Please contact us for quote.


1. High-temperature synthesis of cast materials based on Nb2AlC MAX phase. Ceramics International 45, no. 2 (2019): 2689-2691.

2. Synthesis and characterization of Nb2AlCthin films. Thin Solid Films 517, no. 9 (2009): 2920-2923.

3. Reactive hot pressing and properties of Nb2AlC. Journal of the American Ceramic Society 92, no. 10 (2009): 2396-2399.
