MSE PRO Lithium-Rich Lithium Nickel Manganese Cobalt Oxide NMC 111 Cathode Powder 500g

SKU: PO5009

  • $ 27995
  • Save $ 3400

Bulk orders? Please contact us for Bulk Quotation.

Qty (Each) Price (Each)
1 - 9 $ 279.95
10 - 19 $ 229.95
20 - 20+ $ 181.95

Lithium-Rich Lithium Nickel Manganese Cobalt Oxide

Li1.08-1.12Ni0.33Mn0.33Co0.33O(NMC 111) Powder 500g, 9-12um D50

Product No.: PO5009

Package Size: 500g

Specifications

Appearance: Black powder
Molecular Formula:
  • Li1.08-1.12Ni0.33Mn0.33Co0.33O (nominal Ni:Mn:Co = 1:1:1)

Chemical Name or Material: Lithium Nickel Manganese Cobalt Oxide
Particle sizes:

  • D10: ≥ 5 µm
  • D50: 9 - 12 µm
  • D90: ≤ 20 µm
Tap density: ≥2.3 g/cm3
pH: ≤11.0
BET Specific Surface Area: 0.2 - 0.4 m2/g

      First Discharge Capacity (0.2C, button half open cell):  ~150 mAh/g (4.2 - 2.7V)

      First discharge efficiency: ≥85%

       Parameter Specifications
      Typical Value
      Ni+Co+Mn (wt%) ≥ 57.5 57.83
      Li (wt%) 7.0 ~ 8.0 7.72
      Cu (wt%) ≤ 0.005 0.0006
      Fe (wt%) ≤ 0.01 0.0027
      Na (wt%) ≤ 0.3 0.0077





      References:

      1. Synthesis and characterization of li-rich cathode material for lithium ion batteries, Materials Letters, Volume 273, 15 August 2020, 127927

      Lithium rich (Li-rich) transition metal oxide cathodes are considered to be among the most promising intercalation cathode materials used for lithium-ion batteries (LIBs) with their high energy density above 900 Wh/kg.

      2. S. Phadke and M. Anouti, “Effect of lithium salt concentration on the capacity retention of Lithium rich NMC cathodes,” Electrochim. Acta, vol. 223, no. December, pp. 31–38, 2017.
