MSE PRO Aluminum Fluoride (AlF3) Powder 99.99% Optical Grade

SKU: PO0418

  • $ 32595
  • Save $ 4000

Bulk orders? Please contact us for Bulk Quotation.

Qty (Each) Price (Each)
1 - 9 $ 325.95
10 - 10+ $ 260.95

Optical grade aluminum fluoride (AlF3) powder (99.99% purity) for optical materials, glass and photonics applications

  • CAS Number: 7784-18-1
  • Product Number: PO0418 (250 g)
  • Product Purity: 99.99% (standard purity), other purity levels are available upon request

Chemical Properties for Aluminum Fluoride AlF3 Powder 99.99% Optical Grade

  • Formula: AlF3
  • Formula Weight: 83.98
  • Form: Lump or powder
  • Melting point: 1291°C sublimation
  • Density: 2.882
  • Sensitivity: Hygroscopic
1. Additive for aluminum metal production. Aluminium fluoride (AlF3) is widely used for the production of aluminium by electrolysis as an additive . Used in combination with cryolite, AlF3 lowers the melting point to below 1000°C to form a molten salt that dissolves the aluminum oxide. This melt solution is then electrolyzed to produce aluminum metal.

2. Optical materials and photonics applications. Aluminium fluoride is used in combination with zirconium fluoride as an ingredient for the production of fluoroaluminate glasses. Like magnesium fluoride, aluminium fluoride is also used as a low-index optical thin film, particularly when far UV transparency is required. Its deposition by physical vapor deposition (PVD), particularly by evaporation, is preferred using an aluminum fluoride target.
