Lab Companion Hotplate & Magnetic Stirrers (Multi type) - MSE Supplies LLC

Lab Companion Hotplate & Magnetic Stirrers (Multi type)

  • $ 3,33195
  • Save $ 40000


Lab Companion Hotplate & Magnetic Stirrers (Multi type)

Buy Lab Companion products from MSE Supplies at the best value.

MSE Supplies offers Lab Companion Hotplate & Magnetic Stirrers (Multi type) from Jeio Tech. They allows simultaneous independent stirring available at max. 15 points with stable heating.

Country of Origin: Made in South Korea

Manufacturer: Jeio Tech

Main Features:

  • Instant halt of the stirring operation.
  • Easy-to-read VFD and intuitive control panel.
  • Bright and vivid LED stirring position indicating lamps and heating operation lamp for stable operations.
  • High heat transfer aluminum top-plate.
  • Unit is safely designed to protect internal components from accidental spills.
  • Non-slip silicon plate mat is attached on the top plate to prevent unintended slips
  • Built in thermal shut off and current limit protection.

Accessories:

  • Octahedral magnetic stirring bar
  • Cylindrical magnetic stirring bar
  • Oval magnetic stirring bar
  • Plastic retriever (PP) Plastic retriever (PTFE)
  • Plastic retriever (PTFE)

For accessories, please contact us so we can help you choose appropriate products for your needs.

    Technical Specifications:

    SKU #

    AAHK34013U

    AAHK34023U

    Body

    Material

    Powder coated steel

    Dimension (WxDxH) (inch)

    15.55x17.72x4.09

    15.55x24.17x4.09

    Top plate

    Material

    Aluminum

    Dimension (WxD) (inch)

    15.16x12.91

    15.16x19.41

    Heating

    Temperature range (℃ / ℉)

    Max. 120 / 248

    Control

    Scale

    Heating power (W)

    600

    1000

    Stirring

    Speed range (rpm)

    30 to 2,000

    Control

    Feedback control with PID

    Stirring position

    9

    15

    Stirring point distance (WxD, inch)

    4.61x3.54

    Timer

    1min. to 99 hr. 59 min.

    Motor

    BLDC motor

    Motor rating input / output (W)per each point

    2.9/1.6

    Magnetic bar, Max. (inch)

    0.31x1.18

    Safety

    Over temp.

    Top plate

    Over current

    Current limit protection

    Load, Max (Ibs)

    66.14

    Net weight (Ibs)

    22.05

    33.06

    Electrical requirements (120V, 60Hz)

    8.0 A

    11.2 A


    About Jeio Tech: Jeio Tech products are put through rigorous quality control from the most basic metal processing to final inspections. Based on over 28 years of technical experience in instrument manufacturing, their highly integrated team of engineers strive to deliver outstanding quality to their clients. Their professional know-how will always keep their reputation as the primary partner for the customers research needs.

    MSE Supplies is an authorized distributor for Jeio Tech.
