High Performance Dr. Fritsch GGM 130 Granulating Machine
To better serve you, we would like to discuss your specific requirement, Please Contact Us for a quote.
Dr. Fritsch GGM 130 granulating machine is widely used for granulating metal, ceramic powders and bonds. This is accomplished by rounding fine powders into clusters.
The use of granulate is the prerequisite for volumetric cold pressing and offers the following advantages:
- Reduction of die wear
- Improvement of distribution of powder in the mold
- Reduction of powder dust in the air
Compact granulation machine, ideal for labs
Ideal for wet granulation of small batch sizes started from 500g up to 5kg/hour
process uses binder and solvent
Sieve sizes: 0.4 – 1.2mm
All powder transporting parts can be cleaned easily
Production of granules with very good flow characteristics. Compared to the traditional procedures, the improved process of wet granulating enables the production of finer and rounder shaped granules.
Drying unit with continuously adjustable conveyor belt, temperature controlled radiant heater and extraction system for the alcohol vapors
- Incl. 8 sieves (2 per mesh size: 0.4mm; 0.6mm; 0.8mm; 1.0mm)
Country of Origin: Made in Germany
|Total electric power||6 kVA|
|Supply voltage||3 x 400 V, 50/60 Hz (other voltages and frequencies are possible on request)|
|Total connected load||3 x 9 A|
|Fuses (provided by customer)||3 x 16 A|
standard equipment with active suction
- recommended air flow rate: 800 m³/h (provided by customer)
|Granulate throughput||1 – 5 kg/h|
|Mesh size||0.4 – 1.2 mm|
|Dimensions (W x D x H)||approx. 1,920 x 780 x 1,840 mm|
|Weight||approx. 490 kg|
MSE Supplies LLC is the designated distributor of Dr. Fritsch products in the United States.
