Benchtop Pneumatic Aluminum Laminated Film Case Forming Machine for Pouch Cell Research

To better serve you, we would like to discuss your specific requirement, Please Contact Us for a quote.

Specifications:

MSE Supplies offers a benchtop pneumatic aluminum laminated film case forming machine for pouch cell research. It is widely used to prepare the pouch cell case made of aluminum laminated film. It is compatible with the electrode punched by our "Desktop Pneumatic Die Cutter"

"Pre sealer and heating sealer" is needed to make the final pouch cell.

MSE Supplies is a US-based leading supplier of battery research materials and equipment with thousands of customers worldwide.

About Gelon

Founded in 2003, Gelon is one of world leading battery material and equipment manufacturers. Gelon can provide turn-key projects for lab scale, pilot-line and mass production scale. MSE Supplies is the exclusive distributor of Gelon in U.S.

    SKU BR0249
    Included Die Size 45x62mm (customizable upon request)
    Die Cutting Accuracy ± 0.05mm
    Gas Source Pressure 0.8~1.0MPa air or inert gas
    Punching Pressure Max. 1T
    Punching Thickness Max. 6mm
    Outer Dimension 370x245x336mm
    Aluminum Laminated Film Thickness

    0.1~0.2mm

    MSE Supplies offers 113um thick aluminum laminated film

    Voltage 110V
    Net Weight 45kg
    Warranty One year limited warranty with lifetime product support

    If you name MSE Supplies in your published journal paper or conference abstract, we can offer a one-time 5% discount toward your next purchase.
