The Compact Laboratory Water Chiller is a heat dissipation type chiller without a compressor or refrigerant, it mainly comprises the water tank, circulation pump, heat exchanger, fan, and control components. It utilizes high-speed fans for rapid heat dissipation to cool laser equipment. Its heat dissipation capacity is 50W/°C, meaning it can absorb 50 watts of heat with a 1°C increase in water temperature. This passively cooled Laboratory water chiller is cost-effective and easy to operate, effectively dissipating heat from the spindle while consuming less energy compared to similar products.

The compact structure, ease of operation, space-saving design, energy efficiency, and environmental friendliness make this small laser water chiller widely used for cooling laser engraving, cutting/CNC machines, heating press and also many other laboratory instruments.

It is compatible with our heating press.

Main Features:

Heat dissipation capacity: 50W/℃, which means it can absorb 50W of heat by rising 1°C of water temperature
Passive cooling, no refrigerant
High speed fan
9L reservoir
Digital temperature display
Built-in alarm functions
Easy operation and space-saving
Low energy and environmental

Technical Data

SKU	CH0104	CH0105
Voltage	AC 1P 110V	AC 1P 110V
Frequency	60Hz	60Hz
Current	0.4~0.9A	0.3~0.8A
Max. power consumption	0.07kW	0.11kW
Radiating capacity	50W/℃	50W/℃
Pump	30W DC pump	Diaphragm pump
Max. pump pressure	10M	70M
Max. pump flow	10L/min	2L/min
Protection	Flow alarm	Flow alarm
Tank capacity	9L	9L
Inlet and outlet	OD 10mm Barbed connector	8mm Fast connector
Net weight	9Kg	11Kg
Gross weight	11Kg	13Kg
Dimension	49x27x38cm (LxWxH)	49x27x38cm (LxWxH)
Package dimension	55x34x43cm (LxWxH)	55x34x43cm (LxWxH)

The working current can be different under different working conditions.

The above information is for reference, for more detail or different chillers, please contact us now.
