Neware CE-7002 300V200A EV Battery Testing System
To better serve you, we would like to discuss your specific requirement, Please Contact Us for a quote.
Neware CE-7002, as a new generation testing system with high voltage and high power output capability, is designed for the tests of EV battery and energy storage battery. It has unique IGBT (Insulated Gate Bipolar Transistor) technology which ensures its stable and reliable testing control performance. For the test of battery packs with BMS, CE-7002 has CANBus port to connect your battery BMS and communicate it. For battery packs without BMS, our auxiliary voltage and temperature sensors will help you to detect the voltage and temperature of each single cell in battery packs.
- Response time: ≤10ms
- Accuracy: 0.1% FS
- Minimum pulse width: 500ms
- Data acquisition frequency: 10Hz
The channel number, maximum voltage and current can be customized up request. Please contact MSE Supplies for discussion.
Since 1998, Neware has been committed to providing world-class testing solutions for the batteries and capacitors. Neware has provided flexible, high accuracy battery testing equipment to more than 32,000 customers worldwide ranging from battery manufacturers to R&D institutes, such as Argonne National Lab, LG Chem, Johnson Matthey, 3M, MIT, Stanford University and Princeton University. Customers are satisficed with stable, cost-effective battery testing equipment, along with the great service of Neware. ISO9001:2015 certified.
MSE Supplies is an authorized distributor of Neware in the USA. The product image is for reference only. The actual product appearance is based on product configuration.
MSE Supplies is a US-based leading supplier of battery research materials and equipment with thousands of customers worldwide.
|Neware Model||CE-7002 300V200A|
|Power||AC 380V ±10%/50Hz/60Hz|
|Voltage Accuracy||± 0.1% FS|
|Current Accuracy||± 0.1% FS|
|Current Response Time||≤10ms|
|Maximum Cycle Number||65535|
|Warranty||Limited 1 year warranty. Lifetime technical support|
|Specification link||Neware CE-7002 300V200A|
