MSE PRO™ Ultra High Performance Liquid Chromatography (UHPLC) System, Model 1
Overview
The MSE PRO Model 1 Ultra-High Performance Liquid Chromatography (UHPLC) system is a next-generation instrument designed for the analysis of trace organic components, offering industry-leading performance. With features such as rapid analysis speed and low solvent consumption, it significantly enhances efficiency in large-scale sample detection and analysis.
This advanced UHPLC system is equipped with a high-pressure mixing binary pump capable of reaching a maximum pressure of 20,000 psi. It delivers ultra-low dwell volume and precise gradient control for optimal analytical performance. The accompanying CDS software supports both stand-alone and network deployment, ensuring data security and regulatory compliance.
The MSE PRO Model 1 UHPLC system is ideal for applications in industries such as food, chemicals, pharmaceuticals, and environmental analysis.
Working Environment
1. Operation temperature: 15℃-35℃
2. Operation humidity: 35~80% RH, no condensation
3. Power supply: single-phase power 220±20 V AC, 10A, 50 Hz
System Configuration
1. 1 ultra -high pressure binary gradient pump
2. 1 ultra-high pressure automatic sampler ( optional refrigeration component )
3. 1 diode array detector
4. 1 column oven
5. 1 solvent tray
6. Chromatography software
Specifications
| Ultra-high pressure binary gradient pump | |
| Solvent switching | Through solvent selection valve switching, one of each of the two solutions A1, A2, and B1, B2 can be selected as the system mobile phase |
| Solvent degassing | built-in vacuum degasser, pump A/B binary channels each have independent degassing channels |
| Flow range | 0.010-2.0 mL/min, supports binary gradient method editing |
| Maximum pressure | ≥20000 psi |
| Flow rate accuracy | ± 1.0% @0.5 mL/min |
| Flow rate precision | ≤0.07%RSD or 0.01 min, whichever is greater |
| Dimensions (length × width × height) | 570 mm × 330 mm × 255 mm |
| Weight | about 23 kg |
| Ultra-high pressure automatic sampler | |
| Injection mod | Full loop injection, partial loop injection, microliter injection. |
| Sample loop | 100 μL (standard configuration), other volumes are optional |
| Injection volume | full loop injection 100 μLpartial loop injection 0~50 μLmicroliter injection 0~27 μL |
| Injection repeatability | <0.3%RSD (full loop injection) |
| Carryover | <0.05% |
| Maximum sample capacity | 2*48-bit 1.5ml vials or 2*96-bit multi-well plates or 2*384-bit multi-well plates |
| Dimensions (length × width × height) | 570 mm × 330 mm × 360 mm |
| Weight | about 19 kg |
