MSE PRO KFSH-01 Karl Fischer Oven Sampler for Moisture Analysis, 110V/60Hz
Introduction
The MSE PRO KFSH-01 Karl Fischer Oven Sampler for Moisture Analysis is designed for thermal sample preparation in Karl Fischer moisture testing. It is especially useful for samples that are difficult to dissolve directly in Karl Fischer reagent, release moisture only at elevated temperatures, or may react with the titration solvent.
During testing, the sample is heated in the oven, and the released moisture is transferred by carrier gas into a connected Karl Fischer titrator for water content determination. The KFSH-01 is suitable for moisture analysis of solids, powders, granules, pastes, polymers, chemicals, pharmaceutical materials, battery materials, and other samples requiring indirect Karl Fischer titration.
Key Features
- Designed for Karl Fischer oven moisture analysis
- Adjustable temperature, flow rate, and extraction time
- 40.0–300.0°C heating temperature range
- 0–200 mL/min adjustable gas flow range
- 7-inch high-contrast color LCD touchscreen
- Real-time display of instrument status, temperature, and flow rate
Applications
The KFSH-01 is suitable for moisture determination in:
- Solid and powdered chemicals
- Battery materials and advanced materials
- Polymers, plastics, and resins
- Pharmaceutical powders and excipients
- Food, agricultural, and mineral samples
- Samples that react with Karl Fischer reagent
- Samples with poor solubility in KF solvent
Specifications
| Flow Rate Range | 0–200 mL/min |
| Flow Rate Resolution | 1 mL/min |
| Flow Rate Accuracy | ±10 mL/min |
| Temperature Range | 40.0–300.0°C |
| Temperature Resolution | 0.1°C |
| Temperature Accuracy | ±5°C |
| Display | 7-inch high-contrast color LCD touchscreen |
| Operating Parameters | Temperature, flow rate, minimum extraction time |
| Status Display | Instrument status, operation status, temperature, flow rate |
| Prompt Functions | Indicator prompt and buzzer prompt |
| Work Environment | Ambient temperature: 0–40°C |
| Relative Humidity | ≤85% |
| Power Supply | 110V/60Hz |
| Dimensions | 360 × 240 × 350 mm |
| Net Weight | Approx. 4.5 kg |
Recommended Use
The KFSH-01 can be used together with compatible Karl Fischer titrators for indirect moisture analysis. It is recommended for laboratories that routinely analyze solid, semi-solid, or difficult-to-dissolve samples and require controlled thermal sample preparation before titration.
MSE Supplies offers a variety of electrochemical meters & analyzers, including both benchtop and handheld models, to suit different applications and requirements. Please contact us to discuss your needs.
