MSE PRO High-Precision Moisture Analyzer — 11.1 g, 1.0 µg, N/A (Moisture Analyzer)

Order upon Request
SKU: MA0066692
Regular price $ 14,673.95

Still have questions? Ask our experts!

MSE PRO™ High-Precision Moisture Analyzer — 11.1 g, 1.0 µg, N/A (Moisture Analyzer)

Overview

Color Touchscreen Microbalance

MSE Supplies process has many innovative features like a modern capacitive touchscreen, Automatic draft shield, all-around clear visibility, easy cleaning, and small footprint to deliver the highest accuracy in their class and to help make your micro-weighing tasks simpler and traceable. Usually used to weigh very small expensive, rare or toxic substances, you need to ensure it is the right first time to avoid wasting  of material burdens with money and time. Over this standards such as US Pharmacopoeia / Euramet burden on laboratories to deliver traceable and compliant results.

New Touchscreen works like your smartphone

  • 5.7" large color TFT display
  • The capacitive touchscreen allows you to effortless swipe through operation, configuration, Tasks and Users.
  • Intuitive interface
  • Operable through cotton, silicon or rubber gloves

Touch free operation

  • The draft shield has wide opening, clear visibility and Infrared sensors enable you to open and close the draft shield doors with the wave of a hand.
  • This touch-free balance operation simplify dosing, minimize spills, and reduce cross-contamination.

Digital Level

  • Instead of manually keep track of your level your scale - smart digital level automatically alert once it is out of level and performance can be compromised.  Digital level saves your time and gives you maximum precision in you measurements.

21 CFR Part 11 Compliance

  • Do you work in the pharmaceutical industry? Do you need a digital signature?
  • We are offering the laboratory balance which as a standalone fully meets the
    requirements of 21 CFR Part 11/ EU GMP Annex 11.
    - Full data security
    - Electronic signatures
    - Validations
    - Electronic records
    - Audit trails

Diversity

  • Task can be custom made for each small unique configuration of parameter and make it quick, errorless operation. This saves you time and provides higher productivity.
  • customized print format

Minimum Sample Weight

  • The balance displays whether the value of the weight you are weighing is below or above the minimum weight threshold.
  • 3 MSW method can be configure e.g. USP, GMP and User defined with and Without Tare Weight

Audit-Safe Results

  • Innovative audit safe with its alibi and audit trial functions.
  • As you carry out your operation, your results and changed parameters are automatically recorded on Alibi and Audi trial respectively makes it operation complete audit safe.
  • User management system to ensure secured and authorized use

Easy and Errorless Data transfer saves times

  • You no longer need to record results by hand or spend time typing-in data. Simply transfer task parameters and results to a PC or software application via many interface ports like RS232C, USB A, USB B, Ethernet and wifi. Transcription errors are completely eliminated and the reliability of your data is preserved.

Small Footprint

  • AXR Microbalances are one of the smaller footprint on the market.

Easy Cleaning

  • It is not just small footprint but newly design draft shield provides easy access to weighing pan. All weighing chamber parts can be removed without need of specific tool cleaned and replace back in couple of simple steps.

Product Specifications

Model

MA0066692

Minimum load

100 μg

Repeatability

±1 μg

Linearity

±6 μg

Minimum Sample Weight (U=1% K=2)

0.24 mg

Pan Size

30 mm Ø

Calibration

Motorised Internal Calibration

Operating Temperature

18°C to 30°C

Interface

RS232, USB-A, USB-B, Ethernet direct communication).

Power Supply

A/C Adapter 230 V or 115 V ± 20 % 50 - 60 Hz

Balance Size (WxDxH) mm

Mechanical Box: 360 (L) x 140 (W) x 146 (H) Electronic Box: 240 (W) x 210 (D) x 65 (H)

Maximum Capacity

11.1 gm

Readability

1 μg

Tare Range

- 11.1 gm

Response Time

8 - 10 sec

Minimum Sample Weight (as per USP)

2.4 mg

Display

Colour TFT touchscreen

Units

gm, mg, ct, GN, mo, oz, dwt, t1T, t1H, t1S, mom, Bat, MS

Sensitivity Drift

± 1ppm (1 x 10⁻⁶ / ºC)

Application Modes

PCS, % Weighing, Animal / Dynamic Weighing, Check Weighing, Automatic Density Determination, Formulation Automatic Statistic Calculator etc.

Compliance

21 CFR Part 11 Compliant Password protection

Weight approx.

10.20 kg / 14.70 kg
