MSE PRO™ 1700℃ Muffle Furnace 30 segment controller 7.0 Inch Touch screen – 300×200×200mm, 380V, 12L
Product Description
It is used for sintering, melting and analyzing metal, nonmetal and other compound materials in laboratories of universities, research institutes and industrial and mining enterprises.
Features:
- Mirror stainless steel furnace mouth, long-term use will not change color.
- Vacuum-forming polycrystalline mullite fiber furnace, high efficiency insulation.
- Double shell, the air sleeve heat insulation, and double air guiding passage .
- High-purity silicon-molybdenum rod heating
- High precision program controller, with imported sensor and imported voltage regulating module.
- With leakage protection, thermocouple failure, door opening electrical outage, over-temperature protection and sound-light alarm safety device.
- Lockable handle, quick detachable structure, easy to maintenance and repair.
- Insulated gloves and crucible tongs are standard.
Brand: MSE PRO™
Manufacturer: MSE Supplies LLC
MSE Supplies offers a variety of Climate Chamber with Illuminations. Please contact us for more information.
Specifications:
|
Model |
30 Segment 7.0 Inch Touch Screen controller (Model with PL) |
MA0067488 |
|
Function |
Temp. Range |
Max. 1700℃ (Long time Continuous working Temperature) |
|
Temp. Accuracy |
±1℃ |
|
|
Temp. Resolution Ratio |
1℃ |
|
|
Temp. RISING Time To Max Temp |
<140min |
|
|
Structure |
Furnace Body |
HHR Polycrystalline Mullite Fiber |
|
Outer Shell |
Cold rolling steel with electrostatic Spraying exterior |
|
|
Chamber Size |
300*200*200 |
|
|
Exhaust Hole |
Diφ22, Deφ18 |
|
|
Heater |
HHR Silicon Molybdenum Rod |
|
|
Heating Power |
10KW |
|
|
Controller |
Temp. Control |
7.0-inch touch screen program controller, with curve viewing and USB data storage functions. |
|
Temp. Control Mode |
Intelligent Microcomputer PID Control |
|
|
Display Mode |
Touch Type Operation |
|
|
Timer |
0-9999min |
|
|
Operation Function |
Constant Value Operation Or Program Operation |
|
|
Sensor |
B-type Thermocouple |
|
|
Additional Function |
Heating Start Stop Button, Sensor Fault Alarm, Temperature Overshoot Self Setting, Temperature Correction |
|
|
Safety Device |
Overtemperature Alarm, Leakage Protection, Door Opening Heating |
|
|
Specification |
Exterior Size (W*L*H)(mm) |
750*865*1150 |
|
Packing Size (W*L*H)(mm) |
910*1045*1360 |
|
|
Volume |
12L |
|
|
Current Rating (50/60HZ) |
AC380V, 50Hz |
|
|
NW/GW (kg ) |
150/170 |
|
|
Optional Type |
485 Communication ,U Disk Data Storage |
