Jeio Tech Lab Companion Ultrasonic Cleaners
SKU: BDH532011K
Jeio Tech Lab Companion Ultrasonic Cleaners
Buy Lab Companion products from MSE Supplies at the best value.
MSE Supplies offers Lab Companion Autoclaves (Vertical Type) from Jeio Tech. Industrial B.L.T type ultrasonic transducer (Bolt Clamped Langevin Type Transducer) generates high-frequency sound waves that provide maximum cleaning power.
Country of Origin: Made in South Korea
Manufacturer: Jeio Tech
Main Features:
- Durable / flame resistance ABS material used and cover with 304 stainless steel tanks.
- Over-temperature protection with alarm. (except for UCP-02)
- Digital LED display using splash-proof keypads: timer (1 to 99 min, Max 4 hour operating), temperature monitor. (except for UCP-02)
- High-frequency 40 kHz sound waves provide greater cleaning power and increased reliability.
- Multiple output mode (Normal/Pulse/Sweep) with power selection (Low/Middle/ High). (except for UCP-02)
- Before cleaning, dissolved gas removed by degas function. (except for UCP-02)
- Drain valve, basket, cover as standard offer. (except for UCP-02)
- External and tank parts are made of durable 304 stainless steel.
- Over-temperature protection with alarm.
- Digital LED display using splash-proof keypads: timer (1 to 99 min, Max 4 hour operating), temperature monitor.
- High-frequency 40 kHz sound waves provide greater cleaning power and increased reliability.
- Multiple output mode (Normal/Pulse/Sweep) with power selection (Low/Middle/ High).
- Drain valve, basket, cover as standard offer.
Technical Specifications:
UCP models (ABS, Membrane key pad, and SUS tank)
| Model | UCP - 02 | UCP - 10 | UCP - 20 | |
|---|---|---|---|---|
| SKU# | BDH532011K | BDH532012K | BDH532013K | |
| Electrical requirements (230V, 50 / 60Hz) | 0.6A | 1.3A | 2.2A | |
| Bath volume (L / cu ft) | 2 / 0.07 | 10 / 0.35 | 20 / 0.70 | |
| Temperature range (℃ / ℉) | - | Amb. to 70 / Amb. to 158 | ||
| Ultrasonic power (W) | 100 | 300 | 500 | |
| Dimension | Bath interior (W×L, D) (mm / inch) | 142×132, 104 / 5.6×5.2, 4.1 | 295×240, 160 / 11.6×9.4, 6.3 | 500×290, 160 / 19.7×11.4, 6.3 |
| Exterior (W×L×H) (mm / inch) | 290×210×200 / 11.4×8.4×7.9 | 490×368×297 / 19.3×14.5×11.7 | 721×451×297 / 28.4×17.8×11.7 | |
| Net weight (kg / lbs) | 2 / 4.4 | 11 / 24.3 | 17 / 37.5 | |
UCS models (SUS external and tank)
| Model | UCS-05 | UCS-10 | UCS-20 | |
|---|---|---|---|---|
| SKU# | BDH532031K | BDH532032K | BDH532033K | |
| Electrical requirements (230V, 50 / 60Hz) | 0.9A | 1.3A | 2.2A | |
| Bath volume (L / cu ft) | 5.7 / 0.20 | 10 / 0.35 | 20 / 0.70 | |
| Temperature range (℃ / ℉) | Amb. to 70 / Amb. to 158 | |||
| Ultrasonic power (W) | 200 | 300 | 500 | |
| Dimension | Bath interior (W×L, D) (mm / inch) | 295×160, 160 / 11.6×6.3, 6.3 | 295×240, 160 / 11.6×9.4, 6.3 | 500×290, 160 / 19.7×11.4, 6.3 |
| Exterior (W×L×H) (mm / inch) | 325×230×320 / 12.8×9.1×12.6 | 325×330×320 / 12.8×12.9×12.6 | 530×330×297 / 20.9×12.9×11.7 | |
| Net weight (kg / lbs) | 8 / 17.6 | 11 / 24.3 | 15 / 33.1 | |
About Jeio Tech: Jeio Tech products are put through rigorous quality control from the most basic metal processing to final inspections. Based on over 28 years of technical experience in instrument manufacturing, their highly integrated team of engineers strive to deliver outstanding quality to their clients. Their professional know-how will always keep their reputation as the primary partner for the customers research needs.
MSE Supplies is an authorized distributor for Jeio Tech.
