FILTRA EOLO FTLBA Digital Air Jet Sieve Shaker
SKU: FTLBA
FILTRA EOLO FTLBA Digital Air Jet Sieve Shaker
Overview
The FILTRA EOLO air sweep sieve specially designed for dry grain testing, for a fine particle size, from 5 μm to 4 mm. It offers a great speed and sieving efficiency thanks to the fluidization of the product, obtained by means of a current of air that drags the particles making them pass through the sieve. This effect is achieved with an industrial vacuum cleaner that keeps the depression constant. It has a digital cover with control of sieving time and vacuum meter, which incorporates a depression regulation system. The sieving machine includes a methacrylate lid that allows to see the behavior of the product and a nylon mace to remove any product remains that may have remained in the lid due to static electricity. It is recommended to use Air Sweep sieves FILTRA of Ø200 mm (not included).
Benefits
- Highly effective in the sieving of fine particles: very short sieving times
- Dry sieving
- Ergonomic design
- Digital adjustment of sieving parameters
- Easy to operate
- Integrated interface
- Silent
- Maintenance free
Package
- Air Jet sieve shaker
- Connecting cable
- Methacrylate lid
- Nylon hammer
- User manual
- CE declaration of conformity
Optional Accessories
- Vacuum Unit NILFISK GM80P for FTLBA Air Jet Sieve
- Cyclone For Collection of Fine Particles
- Pack of 5 replacement bags for vacuum unit NILFISK
- Air Jet Test Sieves
Specification
| Sieve Shaker Type | Air jet |
| Dry test | YES |
| Wet test | NO |
| Size of Particle | 5 µm a 4 mm |
| Number of Sieves | 1 |
| Diameter of Sieve (mm) | 200 |
| Timer (min) | 1 to 99 |
| Power Supplies | 220V/60Hz |
| Power (kW) | 0.19 |
| Maximum Depression (Kpa) | 20 |
| Weight (Kg) | 20 |
| Dimensions ØxAl (mm) | 410 x 360 x 362 |
MSE Supplies offers a range of Laboratory Sieve. Please contact us for more information.
