b.safe Y-Connection Tubes for Waste Pipes (L 120mm, 2x Ø 32 mm, 1x GL25 ) (PE-EX )
Regular price
$ 345.95
Couldn't load pickup availability
Still have questions? Ask our experts!
b.safe Y-Connection Tubes for Waste Pipes (L 120mm, 2x Ø 32 mm, 1x GL25 ) (PE-EX )
Product Description
Y-shaped connector made of static dissipative PE-EX, lateral connections include a slope of 2° as well as union nut and clamp ring to insert and clamp b.safe Waste Tubes with O.D. 32 mm. Central connection either with male thread GL25 to assemble b.safe Waste Tubes or straight tube O.D. 32 mm.
Dimensional Drawing
Specifications:
|
Model |
R 1196-01 |
|
Chemical resistance |
++ very good |
|
Conductivity |
1.000 kOhm |
|
Material |
PE-EX |
|
Temperature resistance |
from -50°C to +80°C |
|
Central connection |
GL25 |
|
Form |
y |
|
Lateral connections |
2x Klemmverbindung / clamp connection Ø 32 mm |
|
Total length [mm] |
120 |
Downloadable links:
Technical information
Operating Instructions
