Ampcera Lithium Niobium Oxide, LiNbO3 (1.5 wt%) coated Single Crystal NMC 631 Cathode Powder
SKU: PO0226
Ampcera® LiNbO3 (1.5 wt%) coated Single Crystal NMC 631 Cathode Powder, 3-6um D50, Cathode Material
Product Benefit: LiNbO3 coated Single Crystal NMC 631 Cathode Powder provides superior high rate capability of cathode when being used with solid state electrolyte materials. The coating of LiNbO3 on Single Crystal NMC 631 cathode not only supplied a protective surface coating but also optimized the electrochemical behavior of single crystal NMC 631 cathode material.
Product Number (SKU#): PO0226
Package Size: 10g, 100g
Particle Size:
- D10: ≥1.5 µm
- D50: 3.3~4.5 µm
- D90: 5.5~9.5 µm
Supplier: Ampcera Inc. (Ampcera Inside™)
Specifications (Custom made cathode materials with LiNbO3 coating can be provided by Ampcera Inc. upon request. Please contact us for a quote.)
LiNbO3 Coating: 1.5 wt% of NMC 631
Appearance: Ash black color powder
Molecular Formula: LiNi0.6Mn0.3Co0.1O2 (Ni:Mn:Co = 6:3:1)
Material Type: Single crystal NMC 631 powder
Chemical Name or Material: Lithium Nickel Manganese Cobalt Oxide
Figure is for reference only.
| Parameter | Specifications |
| Ni+Mn+Co (wt%) | 57.3~62.3 |
| Li (wt%) | 7.0~7.6 |
| Ni (mol%) | 59.0±1.0 |
| Mn (mol%) | 30.0±1.0 |
| Co (mol%) | 10.0±1.0 |
| Ca (wt%) | ≤0.0100 |
| Cu (wt%) | ≤0.0020 |
| Fe (wt%) | ≤0.0050 |
| Na (wt%) | ≤0.0300 |
Reference:
- "One‐pot aprotic solvent‐enabled synthesis of superionic Li‐argyrodite solid electrolyte." International Journal of Energy Research 46.12 (2022): 17644-17653.
- "Surface Coatings for Cathodes in Lithium Ion Batteries: From Crystal Structures to Electrochemical Performance." Journal of The Electrochemical Society 169.4 (2022): 043504.
