MSE PRO Programmable Filling System with 1 Pump and Controller - Independent Working Mode
Regular price
$ 1,577.95
Couldn't load pickup availability
Still have questions? Ask our experts!
MSE PRO™ Programmable Filling System with 1 Pump and Controller - Independent Working Mode
Product Introduction
- 7-inch touch screen control, easy and convenient operation.
- One controller can control maximum 8 pump units.
- Each unit working with same or different parameters.
- Pump units can be separately or integrated.
- Different pump units can fit for same or different pump heads.
- Pump can be controlled with touch screen, foot switch, switch signal and communication.
- Two working modes: continuous transferring and dispensing.
- Each unit working independently, can fill same or different volume.
- Support intelligent calibration and online adjusting function ensure the flow rate and dispensing accuracy.
Store RS232/RS485 communication; support external control start/stop; support - missing bottles stop filling function.
- The pump can be integrated or split type.
Technical Parameter
|
Volume resolution |
0.01mL |
|
Time resolution |
0.01s |
|
Back suction angle |
0~360° |
|
Store |
5 parameter programs can be stored and easily recalled |
|
External control method |
Passive switch signal: Foot pedal, Active switch signal: Universal 5~24V |
|
Communication method |
RS232/RS485, supports Modbus protocol (RTU mode) |
|
Pump unit power supply |
AC 220V±10% 50Hz/60Hz (Standard), AC 110V±10% 50Hz/60Hz (Optional) |
|
Controller power supply |
5VDC/2A adapter (Standard) |
|
Temperature |
0~40℃ |
|
Relative humidity |
＜80% |
|
IP rate |
IP31 |
