Witeg Laboratory Bottle With Screw Cap and Pouring Ring
SKU: 5 526 001
Witeg Laboratory Bottle With Screw Cap and Pouring Ring
Buy Witeg products from MSE Supplies at the best value.
Description
- Laboratory bottle, round form
- DURAN® glass
- Acc. to ISO 4796-1
- With graduation
- With screw cap (PP)
- With pouring ring (PP) (25 ml without pouring ring)
Technical data
|
Version
|
DURAN®
|
| Thread |
GL45
|
| Capacity |
1000 ml
|
|
Diameter
|
101 mm
|
|
DIN
|
ISO 4796-1
|
|
Form
|
round
|
| Material |
DURAN® glass
|
|
Accessories`
|
with screw cap and pouring ring (PP)
|
|
Height(outer)
|
230 mm
|
Comparison
| SKU | Model | Version | Autoclavable | Color | Form | Thread | Material | Capacity | Accessories | Diameter | Graduation | Height (outer) |
DIN |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 5 526 001 | Laboratory bottle | DURAN® | round | GL45 | DURAN® glass | 1000 ml | with screw cap and pouring ring (PP) | 101 mm | 230 mm | ISO 4796-1 | |||
| 5 526 002 | Laboratory bottle | DURAN® | round | GL45 | DURAN® glass | 2000 ml | with screw cap and pouring ring (PP) | 136 mm | 265 mm | ISO 4796-1 | |||
| 5 526 005 | Laboratory bottle | DURAN® | round | GL45 | DURAN® glass | 5000 ml | with screw cap and pouring ring (PP) | 182 mm | 335 mm | ISO 4796-1 | |||
| 5 526 010 | Laboratory bottle | DURAN® | round | GL45 | DURAN® glass | 10000 ml | with screw cap and pouring ring (PP) | 227 mm | 415 mm | ISO 4796-1 | |||
| 5 526 015 | Laboratory bottle | DURAN® | round | GL45 | DURAN® glass | 15000 ml | with screw cap and pouring ring (PP) | 268 mm | 450 mm | ISO 4796-1 | |||
| 5 526 020 | Laboratory bottle | DURAN® | round | GL45 | DURAN® glass | 20000 ml | with screw cap and pouring ring (PP) | 288 mm | 510 mm | ISO 4796-1 | |||
| 5 526 025 | Laboratory bottle | DURAN® | round | GL25 | DURAN® glass | 25 ml | with screw cap (PP) | 36 mm | 74 mm | ISO 4796-1 | |||
| 5 526 050 | Laboratory bottle | DURAN® | round | GL32 | DURAN® glass | 50 ml | with screw cap and pouring ring (PP) | 46 mm | 91 mm | ISO 4796-1 | |||
| 5 526 066 | Screw caps for bottles with thread | DURAN® | up to 140°C | lemon yellow | round | GL45 | PP | 1000 ml | with screw cap and pouring ring (PP) | 101 mm | 230 mm | ISO 4796-1 | |
| 5 526 077 | Screw caps for bottles with thread | DURAN® | up to 140°C | green | round | GL45 | PP | 1000 ml | with screw cap and pouring ring (PP) | 101 mm | 230 mm | ISO 4796-1 | |
| 5 526 088 | Screw caps for bottles with thread | DURAN® | up to 140°C | red | round | GL45 | PP | 1000 ml | with screw cap and pouring ring (PP) | 101 mm | 230 mm | ISO 4796-1 | |
| 5 526 099 | Screw caps for bottles with thread | DURAN® | up to 140°C | neutral | round | GL45 | PP | 1000 ml | with screw cap and pouring ring (PP) | 101 mm | 230 mm | ISO 4796-1 | |
| 5 526 100 | Laboratory bottle | DURAN® | round | GL45 | DURAN® glass | 100 ml | with screw cap and pouring ring (PP) | 56 mm | 105 mm | ISO 4796-1 | |||
| 5 526 166 | Pouring rings for bottles | DURAN® | yes | lemon yellow | round | GL45 | PP | 1000 ml | with screw cap and pouring ring (PP) | 101 mm | 230 mm | ISO 4796-1 | |
| 5 526 177 | Pouring rings for bottles | DURAN® | yes | green | round | GL45 | PP | 1000 ml | with screw cap and pouring ring (PP) | 101 mm | 230 mm | ISO 4796-1 | |
| 5 526 188 | Pouring rings for bottles | DURAN® | yes | red | round | GL45 | PP | 1000 ml | with screw cap and pouring ring (PP) | 101 mm | 230 mm | ISO 4796-1 | |
| 5 526 199 | Pouring rings for bottles | with witeg logo and I.D. code | yes | white | round | GL45 | PP | 1000 ml | with screw cap and pouring ring (PP) | 101 mm | yes | 230 mm | ISO 4796-1 |
| 5 526 250 | Laboratory bottle | DURAN® | round | GL45 | DURAN® glass | 250 ml | with screw cap and pouring ring (PP) | 70 mm | 143 mm | ISO 4796-1 | |||
| 5 526 500 | Laboratory bottle | DURAN® | round | GL45 | DURAN® glass | 500 ml | with screw cap and pouring ring (PP) | 86 mm | 181 mm | ISO 4796-1 |
