Witeg Flask Flat Bottom Narrow Neck With Beaded Rim
SKU: 5 514 001
Witeg Flask Flat Bottom Narrow Neck With Beaded Rim
Buy Witeg products from MSE Supplies at the best value.
Description
- flask flat bottom, narrow neck
- with beaded rim
- DURAN® glass
- acc. to DIN ISO 1773 (except 2000 ml, 3000 ml and 5000 ml)
Technical data
| Version | with beaded rim |
| Form | narrow neck |
| Volume | 1000 ml |
| DIN | DIN ISO 1773 |
| Diameter (outer) | neck: 42 mm, max.: 131 mm |
| Material | DURAN® glass |
| Height(outer) | 190 mm |
Comparison
| SKU | Model | Version | Diameter (outer) | Form | Material | Volume | Height(outer) | DIN |
|---|---|---|---|---|---|---|---|---|
| 5 514 001 | flask flat bottom | with beaded rim | neck: 42 mm, max.: 131 mm | narrow neck | DURAN® glass | 1000 ml | 190 mm | DIN ISO 1773 |
| 5 514 002 | flask flat bottom | with beaded rim | neck: 42 mm, max.: 166 mm | narrow neck | DURAN® glass | 2000 ml | 250 mm | DIN ISO 1773 |
| 5 514 004 | flask flat bottom | with beaded rim | neck: 50 mm, max.: 185 mm | narrow neck | DURAN® glass | 3000 ml | 250 mm | DIN ISO 1773 |
| 5 514 006 | flask flat bottom | with beaded rim | neck: 65 mm, max.: 237 mm | narrow neck | DURAN® glass | 6000 ml | 315 mm | DIN ISO 1773 |
| 5 514 010 | flask flat bottom | with beaded rim | neck: 65 mm, max.: 280 mm | narrow neck | DURAN® glass | 10000 ml | 360 mm | DIN ISO 1773 |
| 5 514 050 | flask flat bottom | with beaded rim | neck: 26 mm, max.: 51 mm | narrow neck | DURAN® glass | 50 ml | 90 mm | DIN ISO 1773 |
| 5 514 100 | flask flat bottom | with beaded rim | neck: 26 mm, max.: 64 mm | narrow neck | DURAN® glass | 100 ml | 105 mm | DIN ISO 1773 |
| 5 514 250 | flask flat bottom | with beaded rim | neck: 34 mm, max.: 85 mm | narrow neck | DURAN® glass | 250 ml | 138 mm | DIN ISO 1773 |
| 5 514 500 | flask flat bottom | with beaded rim | neck: 34 mm, max.: 105 mm | narrow neck | DURAN® glass | 500 ml | 163 mm | DIN ISO 1773 |
