Soda-Lime Glass Substrate 25/25/1.1 mm – Pack of 100

  • $ 18480


Soda-lime glass is the most popular glass type used as an insulating substrate for thin/thick film deposition. Soda-lime glass is made by a floating molten glass on a bed of molten tin, assuring uniform thickness and very flat surfaces.

Application Note:
Its smooth and non-reactive surface makes it excellent as a mechanical support for conductive electrode material.

    Specification:
    Density: 2.5 g/cm3
    Young's modulus: (70-75)·109 Pa
    Vickers hardness: 1.35·103 Pa
    Mohs hardness: 6.5·103 Pa
    Poisson's ratio: 0.221±0.1
    Thermal conductivity: 0.95±0.05W/MK at 20 oC
    CLTE: 0~100: 10.2; 0~200: 8.9; 0~300: 8.9; 0~400: 8.9; 0~500: 8.9
    Strain point: 500 oC
    Annealing range: 480-585 oC
    Softening point: 585 oC or 720-740 oC
    Specific heat: 1.10 J/g oC
    Dielectric constant: 7.75·106H at 25 oC (dynamic)
    Resistivity: 5·107 W at 1000 Hz
    Chemical stability: alkali/acid resistance, hydrolyzable

    Product Includes:
    100 pcs of soda-lime glass substrates 25/25/1.1 mm
