MSE PRO High Purity Alumina (Al2O3) Crucible High Form
Product details
High purity alumina (Al2O3) lab crucibles have high melting point, high hardness and good chemical stability. High form alumina crucibles are widely used for chemical calcination, metal casting and ceramic sample preparation.
Click here to order Covers for high purity alumina (Al2O3) crucibles
Powder processing is recommended for the best calcination and sintering results. MSE Supplies offer a variety of balling milling equipment and accessories for powder processing.
Standard Products and Specifications
Purity: >99%
Maximum temperature: 1600 °C
| SKU# | Capacity (mL) | Top Dia. (mm) | Bottom Dia. (mm) | Height (mm) |
| JA1114 | 5 | 26 | 18 | 21 |
| JA1115 | 10 | 30 | 20 | 28 |
| JA1116 | 20 | 38 | 24 | 35 |
| JA1117 | 50 | 50 | 30 | 52 |
| JA1118 | 100 | 61 | 31 | 60 |
| JA1119 | 250 | 90 | 53 | 76 |
Crucible dimensions can be customized upon request. The dimensions listed above are for reference only. Please contact us if you need tight tolerance. Crucible covers are available upon request at an additional cost.
Notes for use
- Place the crucible in 105 °C oven for 2h to remove the moisture before the first use
- Do not heat and cool faster than 5 °C/min <1200 °C or 4 °C/min >1200 °C
