MSE PRO Five-Station Fully Automatic Brinell Hardness Tester
Introduction
The MSE PRO Five-Station Fully Automatic Brinell Hardness Tester is an advanced, high-throughput system designed for precise hardness testing of metallic materials. Equipped with a multi-station automated workflow, motorized Z-axis, and intelligent autofocus system, it enables seamless operation from indentation to measurement. With a wide load range, multiple hardness scales, and integrated digital imaging, this system delivers accurate, repeatable results for industrial quality control and research applications.
Key Features
- Five-station automated testing system for high efficiency and batch testing
- Wide load range from 62.5 kgf to 3000 kgf with automatic closed-loop force control
- Automatic turret with multiple indenters (2.5, 5, 10 mm) and dual objectives for flexible measurement
- Fully automatic autofocus and indentation measurement without manual adjustment
- Integrated 5 MP industrial camera for high-resolution imaging and digital analysis
- Data export in Word and Excel formats with customizable test reports
Specifications
| Category | Specification |
| Hardness Scales | HBW2.5/62.5, HBW2.5/187.5, HBW5/62.5, HBW5/125, HBW5/250, HBW5/750, HBW10/100, HBW10/250, HBW10/500, HBW10/1000, HBW10/1500, HBW10/3000 |
| Test Force Range | 62.5–3000 kgf (612.9–29420 N) |
| Standards | JJG150, GB/T 231.2 |
| Force Accuracy | ≤1% (62.5–250 kgf), ≤0.5% (500–3000 kgf) |
| Measurement Range | 8–650 HBW |
| Measurement Resolution | 0.1 µm |
| Hardness Resolution | 0.1 HBW |
| Dwell Time | 0–99 s |
| Scale Conversion | HV, HK, HRA, HRBW, HRC, HRD, HREW, HRFW, HRGW, HRKW, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T |
| Imaging System | 5 MP industrial digital camera |
| Measurement Modes | Automatic and manual measurement |
| Data Output | Word and Excel formats |
| Calibration | Standard hardness blocks / length scale |
| Control Interface | 15-inch industrial touchscreen computer |
| Max Sample Height | 300 mm (customizable) |
| Throat Depth | 250 mm |
| Dimensions | 700 × 340 × 970 mm |
| Weight | 160 kg |
| Power Supply | AC 110V, 60 Hz |
MSE supplies offers various metallographic equipment, please contact us for more information.
