MSE PRO 30L Natural Convection Oven LED Controller
SKU: MA4145
MSE PRO™ 30L Natural Convection Oven LED Controller
The MSE PRO Natural Constant-Temperature Drying Oven is engineered for precise temperature control in drying, baking, and heat treatment processes. Utilizing natural convection and intelligent temperature regulation, this oven delivers reliable performance with built-in safety and user-friendly features.
- Natural Convection Airflow: Hot air circulates naturally and cyclically for stable and uniform temperature control.
- PID Microcomputer Control: Advanced intelligent temperature controller with over-temperature protection ensures accuracy and safety.
- LED Operation Indicator: Equipped with a standard highlight LED light for clear visibility of instrument operation.
- Safe and Durable Design: Built to support continuous use with efficient heat distribution.
- Anti-Hot Handle: Designed for safety, the new handle minimizes risk of burns during handling.
Brand: MSE PRO™
Manufacturer: MSE Supplies LLC
MSE Supplies offers a variety of Convection Drying Ovens. Please contact us for more information.
Specifications:
| SKU# | MA4145 | |
| Cycle Mode | Natural convection | |
| Function | Temp. Range | RT+10-300℃ |
| Temp. Resolution Ratio | 0.1℃ | |
| Temp. Motion | ±1℃ | |
| Temp. Uniformity | ±3.5% | |
| Structure | Inner Chamber | Mirror Stainless Steel |
| Outer Shell | Cold rolling steel electrostatic spraying exterior | |
| Insulation layer | High quality rock wool board(with CE) | |
| Heater | Nickel chromium alloy heating wire | |
| Power rating | 0.8kW | |
| Exhaust hole | Φ35mmtop(with function of test hole) | |
| Controller | Temp. control mode | Two temperature section PID intelligent |
| Temp. setting mode | Touch button setting | |
| Temp. display mode | Display on LED | |
| Timer | 0-9999min(with timing wait function) | |
| Operation function | Fixed temperature operation, timing function, auto stop. | |
| Additional function | Sensor deviation correction, temperature overshoot self-tuning, internal parameter locking, power-off parameter memory | |
| Sensor | PT100 | |
| Safety Device | Over temperature sound-light alarm | |
| Specification | Inner Chamber size (W*L*H) | 310*310*310 mm |
| Exterior size (W*L*H) | 460*510*695 mm | |
| Volume | 30L | |
| Shelf number | 5 | |
| Load per rack | 15 kg | |
| Shelf space | 40 mm | |
| Current rating (50/60HZ) | AC220V/3.6A | |
| Net Weight | 33 kg | |
| Accessory | Shelf | 2 |
| Shelf frame | 4 | |
| Optional accessories | Spare Shelf; BE model: Spare Shelf, RS485 Interface, Printer, Program controller, U-disk storage; SUSS304 body, 3.5-inch color touch screen tmperature controller. | |
