MSE PRO 1 kg/roll Double Sides Conductive Carbon Coated Copper Foil For Battery Research (260 mm wide 11 µm thick)
Conductive carbon coated copper foil is a trending substrate/current collector in battery R&D and industries. Conductive carbon coated copper foil can be used as an anode material in lithium ion batteries.
Compared with bare copper foil, the conductive carbon coated copper foil has several advantages, such as:
- Improved electrical conductivity and less internal resistance
- Improve adhesion at active layer/current collector interface
- Inhibition of cell polarization and short circuit caused by dendrite growth
- Prevent substrate corrosion caused by electrolyte
The overall cell performance can benefit from these advantages, including higher charge/discharge capacity, better rate capability and cycling performance.
This conductive carbon coated copper foil can be customized upon request, such as coating material, coating thickness and copper foil thickness/width. Please contact us to provide your requirements.
||1 kg per roll|
|Substrate material||Copper (≥99.9% purity)|
|Substrate thickness||9 µm|
|Substrate width||260 mm|
|Coating material||TIMCAL Super P + KS6 Graphite|
|Coating thickness||1 µm|
|Coating side||Two sides|
|Coating width||230 mm|
|Coating density||0.54 g/m2|
|Coating surface resistivity||< 30 ohms per 25um^2|
|Total thickness||11 µm|
