Kern Compound Microscope OBE 111
SKU: OBE 111
Kern Compound Microscope OBE 111
Buy Kern products from MSE Supplies at the best value.
MSE Supplies offers a (Input product type: compound microscope, polarimeter, Refractometer, Microscope Camera, etc.) from KERN & SOHN GmbH. They are the ideal helper for getting started with the analysis of your optically active solutions in the laboratory.
Compound microscopes are used to view small samples that can not be identified with the naked eye. These samples are typically placed on a slide under the microscope. When using a stereo microscope, there is more room under the microscope for larger samples such as rocks or flowers and slides are not required.
The fully equipped all-round compound microscope for school, training and laboratories
Country of Origin: Made in Germany
Manufacturer: KERN & SOHN GmbH
Product Features:
- The KERN OBE series is a range of high-quality, fully-equipped compound microscopes, which can’t be beaten in terms of ease of use and ergonomic design
- The strong and continuously dimmable 3 W-LED guarantees optimum illumination of the samples and also ensures long service life
- The height-adjustable and thereby focusable 1,25 Abbe condenser with aperture diaphragm is a further quality feature of the OBE series and ensures the very best concentration of light.
- Height adjustment of the fully-equipped mechnical stage is carried out using a coarse and fine focusing knob on bothsides. The ergonomically designed coaxial drive enables you to work with the samples and move them rapidly
- A large selection of different eyepieces and objectives, a simple polarising unit and a darkfield kit are available to you as accessories.
- A protective dust cover, eye cups, as well as multi-lingual user instructions are included in the scope of delivery
Product Parameters:
| Optical system | Finite |
| Tube type | Monocular |
| Ocular magnifications | 10 x |
| Ocular visual field | 18 mm |
| Standard objectives | 4×, 10×, 40×, 100× |
| Lens quality | achromatic |
| Nosepiece screw-in locations | 4 |
| Illuminance | Transmitted light |
| Illumination intensity transmitted light | 3 W |
| Illumination type transmitted light | LED |
| Illumination type incident light | none |
| Focusing mechanism | coaxial coarse and fine drive |
| Fine drive minimum | 0,002 mm |
| Dimension (W×D×H) | 320×180×365 mm |
About KERN & SOHN GmbH: Founded in 1844 and manufactured the most accurate balances of its time. Kern's business became the core cell of the internationally famous, southern German precision balance manufacturing. With over 175 years of experience and the devotion to quality have enabled them to become specialists in the weighing field that stands for precision and reliability. Discover the KERN route to success: fast – competent – reliable – versatile!
MSE Supplies is an authorized distributor for KERN & SOHN GmbH.
