Buck Scientific Microdrop 8041 UV-Vis Spectrophotometer
MSE Supplies is an authorized distributor of Buck Scientific instruments.
Buy Buck Scientific products from MSE Supplies at the best value.
Introduction
The Buck Scientific Microdrop 8041 UV-Vis Spectrophotometer is a compact, micro-volume spectrophotometer designed for fast, accurate, and convenient full-spectrum analysis. With both microvolume pedestal and standard cuvette measurement modes, the Microdrop 8041 provides flexibility for a wide range of laboratory applications, including nucleic acid quantification, protein analysis, cell density measurements, kinetics, and general UV-Vis absorbance testing.
Requiring only 0.3–2 µL of sample, the Microdrop 8041 helps conserve valuable samples while delivering results in less than 4 seconds. Its stand-alone 7-inch high-definition touchscreen eliminates the need for an external computer, saving bench space and simplifying daily operation. The stainless-steel/quartz pedestal design allows samples to be applied directly onto the optical surface, held in place by surface tension, and quickly wiped clean after measurement.
Key Features
-
Low Sample Volume
Requires only 0.3–2 µL of sample for rapid analysis. -
Fast Full-Spectrum Detection
Measures from 190 to 1100 nm with results in less than 4 seconds. -
Reliable Optical Performance
Features a xenon flash lamp, 2048-element CMOS detector, and automatic pathlength adjustment. -
Easy Stand-Alone Operation
Built-in 7-inch touchscreen allows operation without an external computer. -
Compact & Easy to Clean
Stainless-steel/quartz pedestal design provides durability, easy sample loading, and quick cleanup.
Specifications
| Model | Microdrop 8041 |
| Instrument Type | Micro-volume UV-Vis Spectrophotometer |
| Minimum Sample Size | 0.3–2 µL |
| Measurement Modes | Microvolume pedestal and standard cuvette |
| Wavelength Range | 190–1100 nm |
| Measurement Time | <4 seconds in pedestal and cuvette modes |
| Light Source | Xenon flash lamp |
| Detector | 2048-element CMOS |
| Pathlength Auto Adjustment | 0.02 mm, 0.2 mm, 1 mm |
| Wavelength Accuracy | ±1 nm |
| Spectral Resolution | ≤1.8 nm FWHM at Hg 254 nm |
| Absorbance Precision | 0.002 AU at 1 mm path; absorbance accuracy ±2% (approximately 1% CV) |
| Absorbance Range | 0.002–750 AU, 10 mm equivalent; accuracy 3% at 0.97 AU, 302 nm |
| Software Compatibility | Windows |
| Connectivity | USB cable to PC for data/software communication |
| Pedestal Material | 303 stainless steel and quartz fiber |
| Display | Built-in 7-inch high-definition touchscreen |
| Display Angle | 10° tilt angle |
| Typical Applications | Nucleic acids A260, proteins A280 and colorimetric assays, cell density OD600, kinetics/time-course, general UV-Vis absorbance |
