Welch 2044 DryFast 1.2 cfm Chemical Duty PTFE Diaphragm Vacuum Pump
Welch 2044 DryFast 1.2 cfm Chemical Duty PTFE Diaphragm Vacuum Pump can be used for vacuum degassing, vacuum impregnation, rotary evaporators, vacuum ovens, vacuum filtering, solid phase extraction, falling film evaporators, rough vacuum distillations, gas recycling, leak detection, gas sampling and many other laboratory and industrial applications.
Constructed with solid PTFE heads, PTFE diaphragms, Kalrez® valves and utilizing fluorinated plastics on all wetted surfaces, these dry vacuum pumps are designed to meet your ever-challenging chemical duty laboratory needs.
It has unique features such as:
• Advanced Vapor Management (AVM)
• Strips DMF fast*
• Chemically resistant
• Oil-free operation
MSE Supplies is an authorized distributor of Welch vacuum pumps.
Additional information found here.
|Free Air Displacement @60Hz, cfm (L/min)||1.2 (35)
|Maximum Vacuum, in. Hg||29.6|
|Ult. Vac. Pressure, Torr||9|
|Motor Horsepower, HP (watts)||1/5 (150)|
|Advanced Vapor Management (AVM)||Yes|
|Tubing Needed, I.D. in. (Inlet/Exhaust)||1/4|
|Intake (Exhaust) Thread NPT||M14/(1/8)|
|Overall Dimensions LxWxH in.||13.8 x 6.8 x 8.8|
|Ship Weight, lbs||25|
