MSE PRO ITO Coated PET Film

SKU: GL0403

  • £21600
  • Save £2700



Transparent Conductive PET Film Coated with Indium Doped Tin Oxide (In-SnO2 or ITO) in rolls or one square meter PET film sheets (ITO/PET)

Applications of ITO Coated PET Film

High quality sputtered ITO films can be used as electrodes for photovoltaic/solar cell, LCD display, flexible display, electro-chemical deposition, biosensors, capacitors, infrared detection applications. Our ITO-coated PET films have also been used as ITO coated EMI shielded plastic windows.

Learn more about our indium tin oxide coated PET films below.

  • Substrate: optically clear PET film
  • PET substrate thickness: 0.175 mm (175 microns) or 0.125 mm (125 microns)
  • Glass Transition Temperature (Tg) of PET is 67-81°C
  • Dimensions: Roll width = 800 mm, length can be customized. One square meter (1 m^2) sheet dimensions: 1250 mm x 800 mm
  • ITO Coating Sheet Resistance Options: 6~10 ohm/sq, 20~30 ohm/sq, 30~40 ohm/sq, 50~80 ohm/sq, 100~140 ohm/sq, other sheet resistance ITO/PET films are available upon request.
  • ITO Coating Thickness: 200 - 350 nm (6~10 ohm/sq), 65 - 95 nm (20~30 ohm/sq), 15 - 25 nm (100~140 ohm/sq)
  • Surface Roughness RMS (5um x 5um area):~ A few nanometers based on AFM
  • Visible Light Transmittance: >85% (100~140 ohm/sq), >83% (20~30 ohm/sq), >75% (5~8 ohm/sq) UV absorption >85%, IR reflection >85%, microwave degradation

Customized sizes and sheet resistance options are available upon request.

ITO Layer thickness information
Specification (Ohm/sq) Sheet Resistance  (Ohm/sq) Thickness  of  ITO Film
500 ≤500 120ű 30Å
150 ≤150 150ű 30Å
125 ≤125 200ű30Å
100 ≤100 230ű 50Å
80 ≤80 300ű5oÅ
60 ≤60 350ű 50Å
50 ≤50 400ű 50Å
40 ≤40 500ű 100Å
30 ≤30 650ű 100Å
20 ≤20 950ű 100Å
15 ≤15 1350ű 150Å
10 ≤10 1850ű 200Å
6 ≤7 2200ű 300Å
5 ≤5 3500ű 300Å
