MSE PRO High Precision Automatic Turret Digital Brinell Hardness Tester - Metallographic Machines - MSE Supplies LLC - MSE Supplies

MSE PRO High Precision Automatic Turret Digital Brinell Hardness Tester

SKU: MA1307

  • $ 11,87995
  • Save $ 1,42601

Request a Quote

MSE PRO™ High Precision Automatic Turret Digital Brinell Hardness Tester

MSE Supplies offers a High Precision Automatic Turret Digital Brinell Microhardness Tester with electro-electric loading, high-precision sensors, and a unique closed-loop control system, each force is automatically compensated.



Brand: MSE PRO™

Manufacturer: MSE Supplies LLC

Main Features:

  • Automatic turret, automatic switching between indenter and objective lens during testing, precise positioning of test points, automatic loading, automatic unloading. It is equipped with dual objective external illumination measurement, which solves the problem of too small or too large indentation to measure. The Brinell external illumination measurement makes the indentation clearer and the measurement more accurate.
  • Eyepiece structure with digital encoder, measuring D1, D2 values, LCD directly displays hardness values and D1, D2 values.
  • Calibration can be done according to standard hardness blocks or length scales.
  • The test force can be automatically corrected by a standard dynamometer.
  • Rockwell and Vickers hardness values can be converted.
  • All data is saved in EXCEL format on a USB drive.

Technical Specifications:

Model MA1307
Brinell hardness scale HBW1/1, HBW1/2.5, HBW1/5, HBW2.5/6.25, HBW1/10, HBW2.5/15.625, HBW5/25, HBW1/30, HBW2.5/31.25, HBW2.5/62.5, HBW5/62.5
Test force (Kgf) 1Kgf(9.8N), 2.5Kgf(24.5N), 5Kgf(49N), 6.25Kgf(61.29N), 10Kgf(98N), 15.625Kgf(153.23N), 25Kgf(245.2N), 30Kgf(294N), 31.25Kgf(306). 47N, 62.5Kgf(612.94N)
Meet the standards BSEN 6506, ISO 6506, ASTM E10, GB/T231
Minimum units of measurement 0.1 um
Hardness value resolution 0.1 HBW
Test the magnification of the microscope 50X(test), 100X(test)
Deadload time 0 to 99 seconds
Data output LCD display
Data storage The measurements are saved in EXCEL format on a USB drive
Maximum allowable specimen height 180mm
The distance from the press head to the machine wall 160mm
Size 590×200×680mm
Weight 50kg
Power supply  220V,50 to 60Hz

    For accessories/consumables and other available models, please contact us so we can help you choose appropriate products for your needs.
