Eyela Peristaltic Pumps
SKU: 251289
Eyela Peristaltic Pumps
Roller set with high discharge pressure and high flow rate stability
- The roller set is integrated and can be easily attached and detached.
- A locking mechanism has been added to the stoppers on both ends of the tubing case. It can be locked when set, making it easy to move and replace tubing.
- A wide range of characteristics can be obtained by adding or changing tubing cases.
- The rotation direction can be easily switched between forward and reverse with just turning the switch.
- High precision discharge with excellent flow rate reproducibility. Suitable for precise liquid dispensing.
- For tubing with an outer diameter ranging from 3 to 6.1mm, MP-2000 and MP-2010 support 2 channels, while MP-2100 and MP-2110 support 4 channels, allowing simultaneous liquid dispensing to 2 or 4 locations.
- Tubing is sold separately. Flow rate, discharge pressure, and other performance may vary slightly depending on the tubing used.
- When the viscosity of the liquid exceeds 0.1Pa·s (100cP), the discharge volume may decrease.
- Not suitable for use with a step-down transformer.
- The liquid temperature specifications are based on the pump body’s heat resistance. The lifespan of the tubing will vary depending on the type of liquid and temperature used.
- The dimensions in parentheses ( ) include protrusions.
Specifications
|
Model |
MP-2000 |
MP-2000A |
|
Cat. No. |
251829 (115V) |
251329 (115V) |
|
Type |
Standard |
Standard |
|
Tubing holder method |
Adjustable screw type |
Fixed-width groove type |
|
Flow rate range |
10 to 1450mL/h × 2 |
10 to 180mL/h |
|
Flow rate accuracy |
Within ±2% (repeatability ±1%) |
Within ±2% (repeatability ±1%) |
|
Max. discharge pressure |
196kPa (2kg/cm²) |
147kPa (1.5kg/cm²) |
|
Max. suction pressure |
9.8kPa (0.1kg/cm²) |
|
|
Fluid viscosity / temp. |
Max. 2Pa·s (2000cP) 0 to 60°C (no freezing) |
|
|
Rotation setting |
Rotation speed control knob |
|
|
Pumping direction |
Forward / reverse switchable |
|
|
Motor |
AC speed control induction motor, 15W |
|
|
Drive circuit |
Speed feedback control |
|
|
Tubing case material |
PET resin |
PVC resin |
|
Safety features |
Thermal protector, Fuse |
|
|
Number of tubes |
2 pcs |
1 pc |
|
Number of tubing cases |
Single stage (can be expanded |
Single stage |
|
Usable tubing material |
Silicone, Tygon®, Versilon®, PharMed® |
|
|
Usable tubing diameter |
3 to 6.1mm OD |
1.15 ID x 3.2mm OD |
|
Ambient temperature range |
0 to 40°C (no condensation) |
|
|
Outer dimensions (mm) |
137(166)W x 145(164)D x 177(190)H |
137(W) × 145(D) × 178(H) |
|
Weight |
Approx. 3.1kg |
Approx. 3.3kg |
|
Power input . supply voltage |
0.2A, 40VA • 220VAC 50/60Hz |
|
