Cleaver Scientific multiSUB Mini Electrophoresis System
Cleaver Scientific multiSUB™ Mini is the smallest unit in the range, designed for low to medium numbers of samples.
The small gel size maximizes run economy but does not compromise versatility as two tray options are available – 7 x 7cm and 7 x 10cm – and combs ranging from preparative up to 16 samples. Simply by altering the gel tray or comb, this compact unit is capable of resolving up to 64 different samples, prepping 1ml of sample or separating sample bands over a distance of 9cm.
For accessories see page 17 and for Power Supplies, see page 60.
Key Features:
multiSUB Mini is the preferred option for quick sample checks of small to medium volumes, particularly following restriction digestion during cloning. Its slim tray format makes MSMINI a very economical choice for separation of up to 64 samples.
- Available with 7 x 7cm, 7 x 10cm or with both gel trays
- Economic low gel and buffer volumes
- Small lab bench footprint
Specifications:
| SKU | MSMINI10 | MSMINI7 | MSMINIDUO |
| Unit Dimensions (cm) | 9 x 21 x 9 | 9 x 21 x 9 | 9 x 21 x 9 |
| Maximum Sample Capacity | 64 | 32 | 64 |
| Base Buffer Volume | 225 | 225 | 225 |
| Buffer Recirculation | No | No | No |
| Flexicaster Options | MS7/10-FC, MS15/20-FC, MS26-FC | MS7/10-FC, MS15/20-FC, MS26-FC | MS7/10-FC, MS15/20-FC, MS26-FC |
| Typical Running Conditions | 80V, 45-60 minutes | 80V, 45-60 minutes | 80V, 45-60 minutes |
| Bromophenol Blue Migration Rate | ~4-5cm/h at 80V | ~4-5cm/h at 80V | ~4-5cm/h at 80V |
| Gel Dimensions | 7 x 10 | 7 x 7 | 7 x 7 & 7 x 10 |
Â
Â
Â
This product includes the following:
Check out the accessories and combs compatible with Cleaver Scientific multiSUB Mini Electrophoresis System
