SO-LOW General Purpose Incubator
Specifications
|
Model No. |
SMI2 |
SMI6 |
SMI7 |
SMI11 |
SMI12 |
SMI31 |
SMI39 |
|
Manufacturer |
Sheldon |
- |
|||||
|
Capacity [ Cubic Feet ] |
2 |
5.9 |
6.5 |
10.9 |
11.7 |
30.8 |
38.6 |
|
Capacity [ Liters ] |
56 |
166 |
184 |
309 |
332 |
872 |
1093 |
|
Temperature Range [ °C ] |
Ambient + 8°C to 70°C |
8°C above ambient to 70° |
|||||
|
Temperature Range [ °F ] |
Ambient + 46°F to 158°F |
||||||
|
Dimensions |
[ W x D x H ] |
||||||
|
Exterior [ Inches ] |
21.3” x 22.3” x 26” |
25.3” x 27.3” x 38” |
30” x 31” x 32” |
42” x 27” x 38” |
25.3” x 27.3” x 76.0” |
38” x 32.5” x 73.3” |
41.5” x 32.8” x 90.3” |
|
Interior [ Inches ] |
15” x 15” x 15.2” |
19.5” x 20” x 26” |
23.7” x 24” x 20” |
36.2” x 20” x 26” |
19.5” x 20” x 26” |
32.6” x 26” x 64.1” |
35.6” x 26” x 76” |
|
Exterior [ Centimeters ] |
54 x 56 x 66 |
64 x 69 x 96 |
76 x 78 x 81 |
106 x 68 x 96 |
64 x 69 x 193 |
96 x 82 x 186 |
105 x 83 x 229 |
|
Interior [ Centimeters ] |
38 x 38 x 38 |
49 x 50 x 66 |
60 x 61 x 50 |
92 x 50 x 66 |
49 x 50 x 66 |
82 x 66 x 162 |
90 x 66 x 193 |
Electrical Specifications
|
Voltages Available |
115 Volts 60 Hertz 1 Phase |
|
Amperage |
15 Amp Dedicated Line |
|
NEMA Configuration |
NEMA 5-15 |
|
Certification(s) |
UL Listed |
Control Specifications
|
Temperature Control |
Microprocessor, Digital Display |
|
Touchscreen |
7" Display |
|
Temperature Alarm |
Audible High / Low Alarm |
|
Additional Alarms |
Door Ajar Alarm |
|
Alarm Relay |
Dry Contacts |
|
Additional Output |
4-20mA Output |
|
Data Logging |
Yes, Adjustable Intervals |
|
Data Download |
USB A Port |
|
Temperature Uniformity |
+/-0.5°C ( at 37°C ) |
General Specifications
|
Air Circulation |
Forced Air |
|
Jacket Type |
Air |
|
Opening |
1 Front Door |
|
Opening Type |
Hinged |
|
Inner Door Material |
Glass |
|
Outer Door Material |
Painted Steel, Heated |
|
Access Porthole |
1 1/2" Diameter |
|
Storage |
2 Adjustable Shelves |
|
Exterior |
Painted Steel |
|
Interior |
Stainless Steel |
|
Interior Outlet |
One, 1 Amp |
|
Warranty |
2 Years Parts and Labor |
Product Specifications
General purpose incubators deliver a degree of temperature uniformity usually found only in more expensive, application specific models. This high level of performance is due to a precise microprocessor controller and a unique warm air jacket design. Triple wall construction allows heated air to circulate within an open plenum between the inner chamber and exterior walls. This design does not require blowers or fans within the incubator chamber where samples are susceptible to cross contamination and the drying effects of convection. Five strategically placed heating elements, including a heated outer door; ensure uniform heating, even when the incubator chamber is fully loaded. The General Purpose Incubator Family ranges in size from 2 to 40 cu. ft. This superior line of incubators has created a level of comfort and convenience for professionals that are unrivaled.
|
Model No |
SMI6 |
SMI7 |
SMI11 |
SMI12 |
SMI31 |
SMI39 |
|
Microprocessor Control |
Viewing Door |
Powder Coated White Interior |
||||
|
Viewing Window |
- |
Six Shelves |
||||
|
Roller Bottle Apparatus Accommodation |
- |
Access Port |
||||
|
Independent Overtemperature Thermostat |
Small Foot Print |
- |
||||
|
Unique Warm Air Jacket Design |
Stainless Steel Interior (GI Series Only) |
- |
||||
|
Interior Outlet |
UL Approval |
24 Month Limited Warranty |
||||
|
Heated Outer Door (GI Series Only) |
24 Month Limited Warranty |
- |
||||
Features
|
SKU |
SMI6 |
SMI7 |
SMI11 |
SMI12 |
SMI31 |
SMI39 |
|
Weight |
185 lbs |
195 lbs |
- |
425 lbs |
600 lbs |
625 lbs |
|
Capacity |
6.0 cu.ft. |
6.7 cu.ft. |
11.3 cu.ft. |
12 cu.ft. |
31.8 cu.ft. |
40 cu.ft. |
|
Interior Dimensions WxDxH in. (cm) |
19 x 20 x 26 (49 x 51 x 66) |
24 x 24 x 20 (61 x 61 x 51) |
36 x 20 x 27 each chamber (91 x 51 x 69) |
20 x 20 x 26 each chamber (51 x 51 x 66) |
33 x 26 x 64 (84 x 66 x 163) |
35 x 26 x 76 (89 x 66 x 193) |
|
Exterior Dimensions WxDxH in. (cm) |
25 x 27 x 37 (64 x 69 x 93) |
30 x 30 x 32 (76 x 77 x 81) |
42 x 27 x 37 (107 x 69 x 94) |
25 x 27 x 74 (64 x 69 x 188) |
39 x 33 x 75 (98 x 83 x 191) |
41 x 34 x 87 (104 x 86 x 221) |
|
Temperature Range |
8°C above ambient to 70°C |
Ambient +8 to 70°C |
8°C above ambient to 70°C |
|||
|
Temperature Uniformity |
+/-0.35°C at 37°C |
+/-0.8°C at 37°C |
||||
|
Electrical Specifications |
Volts: 120V Hertz: 50/60Hz Watts: 700W |
Volts: 120V Hertz: 50/60Hz Watts: 650W |
Volts: 120V Hertz: 50/60Hz Watts: 850W |
Volts: 120V Hertz: 50/60Hz Watts: 650W |
Volts: 120V Hertz: 50/60Hz Watts: 1485W Amps: 8.5A |
Volts: 120V Hertz: 50/60Hz Watts: 1650WAmps: 12.5A |
|
Jacket Type |
Air |
- |
||||
|
Shelving |
3 Supplied (12 Maximum) |
2 Supplied (9 Maximum) |
6 Supplied (12 Maximum) |
6 Supplied (24 Maximum) |
6 Supplied (16 Maximum) |
6 Supplied (20 Maximum) |
|
Access Port |
Yes |
One |
Available Option |
|||
|
Interior Outlet |
One |
One each |
Four |
|||
