MSE PRO™ Multi‑Channel Temperature Verification System

Description

The MCT Temperature verification system is an innovative real-time device meticulously crafted for validating the temperature control precision of laboratory instruments. This system integrates a high-precision PT1000 sensor with a cutting-edge signal acquisition system, ensuring remarkable linearity and rapid response times. It enables real-time monitoring of temperature accuracy, uniformity, stability, and ramping rate in PCR equipment. This makes it an indispensable tool for temperature control equipment manufacturers, equipment maintenance service centers, and metrology laboratories.
The equipment is compact and can work with external power supply, which is convenient for on-site inspection.
It is suitable to measure below PCR/QPCR devices:

• 96-well PCR/QPCR
• 384-well PCR/QPCR
• 8/16/48-well PCR/QPCR
• deep well plate
• Dry bath incubator etc. devices

Features

• Manufacturers of Thermal cycler (PCR), Real-time Quantitative PCR(qPCR), Dry block heater, Water Bath, Incubator, for the instrument temperature calibration in development, production and quality control;
• On-site installation checking, temperature calibration and instrument performance qualification of PCR, qPCR, Dry block heater, Water Bath, Incubator equipment;
• Routine maintenance, inspection and calibration of laboratory temperature control equipment;
• Optimization of temperature control process for PCR reagent development;

• Multiple probes are suitable for tube mode, plate mode and other customized probe. The high-precision PT sensor is wrapped with metal, which can precisely detect the actual  temperature of the machine;

• Real-time acquisition in multi-channels allow the detection of temperature deviation between different wells of PCR instrument, effectively monitoring the temperature edge effect  of the well plate;


• High-speed temperature acquisition up to 20 channels /0.5S, suitable for most real-time data acquisition of  ramping rate below 10℃/S in the PCR tube, without
  losing temperature data;


• The device comes with easy-to-use software and supports temperature accuracy and uniformity measurement in stable period, analysis and measurement of heating and cooling speed, dynamic tracking of temperature curve. It supports temperature curve selection, marking, tracking and data export to excel for further analysis;
