Ninefold bundle capillaries
With their 9 channels, the capillaries arranged symmetrically in layers form the square total cross-section. The individual channels are made with solid walls, however these walls can be manufactured to be thinner, depending on the application. These capillaries are mainly used in electrophysiology and electrochemistry.
Sevenfold bundle capillaries
-
Made from borosilicate glass
| SKU# | Outer Ø (mm) | Inner Ø (mm) | Wall thickness (mm) | Filament (mm) | Length (mm) |
| 1406809 | 1.00 ± 0.05 | 0.560 ± 0.05 | 0.22 | 0.1 | 75.00 |
| 1406801 | 1.00 ± 0.05 | 0.560 ± 0.05 | 0.22 | 0.1 | 100.00 |
| 1406802 | 1.00 ± 0.05 | 0.560 ± 0.05 | 0.22 | 0.1 | 150.00 |
