SO-LOW Flammable Material Storage Refrigerators
Couldn't load pickup availability
Still have questions? Ask our experts!
SO-LOW Flammable Material Storage Refrigerators
Specifications
|
Model No. |
MV4-6UCFMSR |
DHH4-14SDFMS |
DHH4-17SDFMS |
DHH4-20SDFMS |
DHH4-30SDFMS |
|
Manufacturer |
So-Low |
||||
|
Capacity [ Cubic Feet ] |
5 Cubic Feet |
14 Cubic Feet |
17 Cubic Feet |
20 Cubic Feet |
30 Cubic Feet |
|
Capacity [ Liters ] |
141 Liters |
396 Liters |
481 Liters |
566 Liters |
849 Liters |
|
Temperature Range [ °C ] |
1°C to 7°C |
1°C to 10°C |
1°C to 10°C |
||
|
Temperature Range [ °F ] |
33°F to 50°F |
||||
|
Dimensions |
[ W x D x H ] |
||||
|
Exterior [ Inches ] |
23.75" x 24.25" x 32.25" |
23.5" x 24.25" x 73" |
30.75" x 28.5" x 67.75" |
30.75" x 29" x 74.5" |
35.75" x 35.5" x 72.5" |
|
Interior [ Inches ] |
20.25" x 17" x 27" |
19" x 16.75" x 63.75" |
26.25" x 20.75" x 58.5" |
24.75" x 20.75" x 65.25" |
32" x 22.5" x 65" |
|
Exterior [ Centimeters ] |
60 x 61 x 81 |
59 x 61 x 185 |
76 x 72 x 172 |
78 x 73 x 189 |
90 x 90 x 184 |
|
Interior [ Centimeters ] |
51 x 43 x 68 |
48 x 42 x 162 |
66 x 52 x 148 |
63 x 53 x 166 |
81 x 57 x 165 |
Electrical Specifications
|
Model No. |
MV4-6UCFMSR |
DHH4-14SDFMS |
DHH4-17SDFMS |
DHH4-20SDFMS |
DHH4-30SDFMS |
|
Voltages Available |
115 Volts 60 Hertz 1 Phase |
||||
|
Amperage |
15 Amp Dedicated Line |
15 Amp Dedicated Line |
15 Amp Dedicated Line |
||
|
NEMA Configuration |
NEMA 5-15 |
||||
|
Certification(s) |
UL Listed |
ETL Listed |
UL Listed |
||
Control Specifications
|
Model No. |
MV4-6UCFMSR |
DHH4-14SDFMS |
DHH4-17SDFMS |
DHH4-20SDFMS |
DHH4-30SDFMS |
|
Temperature Control |
Digital Display |
Adjustable Mechanical |
|||
|
Min / Max Temperature |
Display and Reset |
||||
|
Temperature Alarm |
Audible High / Low Alarm |
||||
|
Battery Backup |
Only Powers Alarm |
- |
|||
|
Additional Sensor |
1 Air Sensor |
- |
|||
|
Alarm Relay |
Dry Contacts |
- |
|||
General Specifications
|
Model No |
MV4-6UCFMSR |
DHH4-14SDFMS |
DHH4-17SDFMS |
DHH4-20SDFMS |
DHH4-30SDFMS |
|
Defrost |
Cycle |
Manual |
|||
|
Air Circulation |
Gravity Flow |
Forced Air |
Gravity Flow |
||
|
Compressor(s) |
Hermetic Compressor |
||||
|
Refrigeration |
R600a |
R404A |
|||
|
Insulation |
High Density Urethane |
Polyurethane Foam |
|||
|
Opening |
1 Front Door |
||||
|
Opening Type |
Hinged |
||||
|
Door Material |
Insulated Steel |
||||
|
Lockable Door |
Keyed Lock |
||||
|
Access Porthole |
3/8" Diameter |
3/4" Diameter |
- |
||
|
Storage |
3 Adjustable Shelves |
5 Adjustable Shelves |
|||
|
Exterior |
Painted Steel |
||||
|
Interior |
Painted Steel |
||||
|
Leveling Legs |
4 |
||||
|
Warranty |
2 Years Parts and Labor |
||||
