MSE PRO 625L Electric Forced Air Drying Oven with 4.3‑inch Color Touch Screen and Program Controller
Regular price
$ 5,709.95
Couldn't load pickup availability
Still have questions? Ask our experts!
MSE PRO 625L Electric Forced Air Drying Oven with 4.3‑inch Color Touch Screen and Program Controller
Application:
- Drying
- Baking
- Wax Melting
- Heat Treatment
Product Features:
- 4.3‑inch color touch screen controller with intelligent predictive PID control, offering smaller overshoot, faster stabilization, and higher precision than conventional PID.
- Historical data export via USB, curve viewing, alarm records, operation logs (audit trail), three‑level authority management.
- Temperature control modes: constant mode and program mode. Constant mode supports constant temperature timing or operation timing. Program mode includes 9 programs with up to 100 segments each.
- Scheduled startup function automatically runs at preset time.
- Three‑point temperature calibration, sensor fault, over‑temperature, under‑temperature alarms. Heating output automatically cuts off during alarm for high safety.
- Circulating fan with multi‑level adjustable speed via touch screen, ensuring excellent temperature uniformity.
Technical Parameters:
| Model | WGLL‑625BL |
| Circulation | Forced convection |
| Temp range | RT+10–300°C |
| Resolution | 0.1°C |
| Temp fluctuation | ±1°C |
| Uniformity | ±2.5% |
| Chamber material | Mirror stainless steel |
| Inner Chamber Size W*L*H (mm) | 602*660*1250 |
| Exterior Size W*L*H (mm) | 760*942*1739 |
| Packing Size W*L*H (mm) | 1032*1009*1925 |
| Rated power | 4.0KW |
| Inner volume | 625L |
| Power supply | AC380V |
| Safety Devices | High‑precision digital independent over‑temperature protector, audible and visual over‑temperature alarm. |
| Optional Configurations | Additional shelves, RS485 interface, printer, WIFI control module |
