High Purity (>95 wt%) Single-walled Carbon Nanotubes (Floating Catalyst Method), 1g,  MSE Supplies

High Purity (>95 wt%) Single-walled Carbon Nanotubes (Floating Catalyst Method), 1g

  • €22595


Product details:

High Purity (>95 wt%) Single-walled Carbon Nanotubes (Floating Catalyst Method)

Package size: 1 g per bottle

Product SKU# PO5004

This single-walled carbon nanotube (CNT) is produced by the floating catalyst CVD method and acid purified. Compared with the moving catalyst type single-walled carbon nanotube, it generally requires a surfactant to dispersion well in solvents.  It is an economical option for conductive thin film application when high transparency is not required.

    Due to its high thermal and electrical conductivity, it is also can be used for applications such as: additives in polymers, catalysts, electron field emitters for cathode ray lighting elements, gas-discharge tubes in telecom networks, electromagnetic-wave absorption and shielding, lithium battery, sensors, reinforcements in composites and Supercapacitor.

    This carbon nanotubes can be functionalized by -OH, -COOH and -NH2. It also has a short length version (1~3 um).

    MSE Supplies offers a variety of CNT products, include CNTs powder, CNTs paste, CNTs
    array, CNTs fiber, CNTs film, CNTs film adhesive tape, CNTs conductive heating coating, CNTs thermal radiation coating, CNTs transparent static conductive coating, CNTs conductive fillers, CNTs functional masterbatches, CNTs epoxy composite, etc. Please contact us at sales@msesupplies.com to discuss your need.

    Specifications:

    Property Unit

    High Purity Single-walled Carbon Nanotubes

    Method of Measurement
    SKU# PO5004
    OD nm 1-2 HRTEM, Raman
    SWCNTs Purity wt% >95 TGA & TEM
    Length microns 5-30 TEM
    SSA m2/g 690 BET
    ASH wt% < 5 HRTEM,TGA
    EC s/cm >100
    Tap Density g/cm3 0.127
    OD=Outer Diameter               ID=Inner Diameter                SSA=Special Surface Area

    Reference:

    1. Effects of Functionalization on Thermal Properties of Single-Wall and Multi-Wall Carbon Nanotube–Polymer Nanocomposites, ACS Nano 2013, 7, 6, 5114–5121

    2. Porous Amorphous FePO4 Nanoparticles Connected by Single-Wall Carbon Nanotubes for Sodium Ion Battery Cathodes, Nano Lett. 2012, 12, 11, 5664–5668
