Ti<sub>3</sub>AlC<sub>2</sub> MXene Multilayer Micron-Powder - MSE Supplies LLC

Titanium Aluminum Carbide (Ti3AlC2) MAX Phase Micron-Powder

  • $ 11700


Titanium Aluminum Carbide (Ti3AlC2) MAX Phase Micron-Powder

  • Chemical Name: Titanium Aluminum Carbide
  • CAS Number: 196506-01-1
  • Product Number: 1g (PO6713); 5g (PO6714); 10g (PO6715)
  • Appearance: Black Powder
  • Particle Size: 0.5-25μm
  • Purity: ≥90 wt.%

Applications

Titanium Aluminum Carbide (Ti3AlC2) belongs to the family of Mn+1AXn (MAX) phases with more than 80 members. These are layered, machinable, nanolaminated ternary carbides, nitrides and borides, where M is an early transition metal, A is an A-group element, mainly from groups 13–16 and X is C or N or B. These compounds possess hexagonal crystal structure with space group P63/mmc (space group number: 194), where M atoms are in a near closed packed arrangement and are intercalated with A-group atomic layers, with the X-atoms residing in the octahedral sites between the M layers. These atomic arrangements give the MAX phases an effective laminated layered structure that leads to the naming of the MAX phase as nanolaminates. MAX phases possess a unique combination of properties, both metallic and ceramic in nature due to the layered structure. Metallic properties can include good thermal and electrical conductivities, good thermal shock resistance, excellent damage tolerance, and good machinability. Ceramic properties include low density, elastic rigidity, oxidation and creep resistance, and the ability to maintain the strength up to very high temperatures.

Ti3AlC2 exhibits a surprising combination of good properties of ceramics and metals. It is relatively soft (Vickers hardness of ∼3.5 GPa) and elastically stiff (Young's modulus of 297 GPa and shear modulus of 124 GPa). It is lightweight (density of 4.2 g cm−3) and easily machinable. It has good thermal and electric conductivities. Such unique properties make it with a wide variety of potential applications in high-tech field, e.g. abrasion-resistant components, elements of chemical equipment, etc.

Notes: More detailed product information including SDS, certificate of analysis (COA), lead time and volume pricing are available upon request. Please contact MSE Supplies if you need bulk pricing.

MSE Supplies also offers Ti3AlCdispersions. Please contact us for quote.

References

1. Effects of Al substitution by Si in Ti3AlC2 nanolaminate. Scientific reports 11, no. 1 (2021): 1-11.

2. Halogen etch of Ti3AlC2 MAX phase for MXene fabrication. ACS nano 15, no. 2 (2021): 2771-2777.

3. Molybdenum Oxide Supported on Ti3AlC2 is an Active Reverse Water–Gas Shift Catalyst. ACS sustainable chemistry & engineering 9, no. 14 (2021): 4957-4966.

4. Synthesis of Ti3AlC2 ceramic by high-energy ball milling of elemental powders of Ti, Al and C. journal of materials processing technology 209, no. 2 (2009): 871-875.
